AGM Rattler TS25-384 Thermal Imaging Rifle Scope 384x288 50hz 25mm Lens

AGM Rattler TS25-384 Thermal Imaging Rifle Scope 384x288 50hz 25mm Lens

AGM Global Vision
SKU:
810027778093
$1,995.00
(No reviews yet)
Current Stock:

Out of stock

Out of Stock
Description
Characteristics

Detector type: 17μm, Uncooled, 50Hz

Refresh rate: Sensor 50 Hz / OLED 50 Hz

Resolution: 384x288

FOV: 14.9° x 11.2°

Package Includes
  • Mount
  • USB Cable
  • Lens Tissue
  • User Manual
  • Carrying Bag
  • CR 123 Batteries
Downloads
Data Sheet
User Manual

Description And features

The Rattler TS25-384 is a perfect addition to any hunter's arsenal. Equipped with a 25mm germanium lens and a 384x288 resolution thermal sensor, this unit has a detection range of 880 yards, and a base magnification of 1.5X. This low base magnification allows for a wide field of view, which many hog hunters prefer, as it allows them to see and track multiple animals in a group at once. The Rattler series of thermal scopes were specifically designed to be compact and lightweight, as this not only ensures its small footprint can be used on a multitude of shooting platforms, but also gives the series secondary use as a thermal monocular as well.

This unit also comes packed with all the features that many Rattler users have come to expect, which include: built-in recording and picture capture capabilities, Wi-Fi hotspot, 8X digital zoom, Picture-in-picture, AGM Connect app compatibility for storing and sharing images and videos, one-shot digital zeroing process, 4.5 hours of battery life on (2) CR123 batteries, external power capability through the unit’s USB-C plug and a high-quality American Defense Manufacturing quick detach mount which quickly allows users to seamlessly shift from riflescope to monocular quickly and easily.



  • 384 × 288 thermal resolution, high sensitivity detector (NETD <35mK)
  • Image processing technology: Adaptive AGC, DDE, 3D DNR
  • 1024 × 768 resolution 0.39-inch OLED display
  • 8x digital zoom
  • Video recording and snapshot, built-in EMMC (16 GB)
  • Supports distance measurement
  • Picture In Picture Mode (PIP)
  • Adjustable color palettes
  • Wi-Fi data transmission
  • Waterproof, shockproof
  • Up to 4.5 hours continuous working
  • External power supply capability
  • 5-Year warranty

Specifications

Shock and vibration: 750 g/ms

Picture In Picture Mode (PIP): Yes

Digital Magnification: 1.5x - 12x

Detector type: 17μm, Uncooled, 50Hz

Standby Mode: Yes

Resolution: 384x288

Detection Range (6' object): 1250m/yd

Snapshot: Yes

Lens system: 25 mm; F/1.0

Field of view (H × X): 14.9° x 11.2°

Digital zoom: 2x, 4x, 8x, PIP

Eye relief: 45 mm

Imaging palettes: Jungle, Recognition

Display: 0.39-inch, OLED, 1024 × 768

Storage: Built-in EMMC (16 GB)

Record Video: Yes

Battery Type: Two CR123A (3V) Lithium or two RCR123 (up to 4.2V) Rechargeable Batteries

Wi-Fi: Yes

Battery Life (Operating): Up to 4.5 hr

External power supply: 5V USB

Operating Temperature Range: -20°C to +55°C (-4°F to +131°F)

Degree of Protection: IP67

Weight: 0.41 kg ( 0.91 lb)

Overall Dimensions: 187.2 × 62.5 × 59.2 mm (7.37 × 2.46 × 2.33 in)

Magnification: 1.5x
